VSWR &Return Loss
| Frequency （MHz） | 2400 | 2450 | 2500 | 5150 | 5550 | 5850 |
| Return Loss | -21.63 | -19.34 | -14.27 | -6.96 | -11.83 | -5.84 |
| VSWR | 1.18 | 1.25 | 1.48 | 2.63 | 1.71 | 3.09 |
VSWR
Return Loss
| Frequency(MHz) | 2400 | 2450 | 2500 | 5150 | 5550 | 5800 |
| Efficiency(% ) | 80.09 | 81.81 | 79.11 | 54.68 | 61.04 | 57.09 |
| Gain .dBi | 4.45 | 4.22 | 3.97 | 2.4 | 3.94 | 1.99 |
