| Frequency Point（MHZ） | 700 | 960 | 1710 | 2170 | 2300 | 2690 | 3300 | 4200 | 4400 | 5000 |
| VSWR（dBi） | 1.73 | 2.14 | 1.147 | 1.34 | 1.22 | 1.8 | 1.61 | 1.58 | 1.08 | 1.97 |
| Return loss | -10.85 | -10.91 | -23.67 | -16.61 | -20.18 | -10.7 | -12.45 | -12.84 | -28.09 | -9.63 |
VSWR
Return loss
| Frequency（MHZ） | 700 | 820 | 960 | 1710 | 1960 | 2170 | 2300 | 2500 | 2690 | 3300 | 4200 | 5000 |
| Efficiency [%] | 44.4 | 48.5 | 30.8 | 69.4 | 69 | 70.8 | 69.7 | 66.6 | 64.7 | 74 | 46.6 | 57.3 |
| Peak Gain [dBi] | 0.73 | 1.41 | 1.25 | 1.62 | 0.93 | 2.99 | 2.52 | 2.72 | 2.26 | 2.4 | 2.3 | 2.48 |
