VSWR &Return Loss
| Frequency （MHz ） | 820 | 960 | 1710 | 2170 | 2300 | 2690 |
| VSWR | 3.32 | 2.54 | 1.4 | 2.09 | 1.48 | 1.85 |
| Return Loss | -5.41 | -8.39 | -14.97 | -8.72 | -15.83 | -10.54 |
VSWR
Return Loss
| Frequency(MHz) | 820 | 890 | 960 | 1710 | 1950 | 2170 | 2300 | 2500 | 2690 |
| Efficiency(% ) | 32.21 | 58.34 | 54.93 | 48.78 | 56.78 | 62.88 | 69.19 | 52.72 | 60.08 |
| Gain（dB） | -1.44 | 4.06 | 4.48 | 3.52 | 2.22 | 3.32 | 4.63 | 2.98 | 3.49 |
